The selection of steel not only affects the service life of injection molds, but also the cost of mold opening. Some characteristic plastic products may require the use of specific materials. Because the selection of materials is particularly important when opening injection molds. The following is an introduction to the characteristics and applicable products of several commonly used mold materials.
What are the commonly used mold steels?
1、 P20 steel.
P20 steel is a pre hardened mold steel, with a domestic grade of 3Cr2Mo, widely used in the manufacture of injection molds with low to medium complexity and small to medium batch sizes.
core features
1. Pre hardened state
It has undergone quenching and tempering treatment before leaving the factory, pre hardened to 30-35 HRC, and can be directly processed without the need for secondary heat treatment. Uniform hardness distribution, suitable for high-precision machining.
2. Processing performance
Good machinability, suitable for CNC milling, electrical discharge machining (EDM), etc. Medium polishing performance, up to # 2000- # 4000 mesh.
3. Wear resistance and toughness
Moderate wear resistance, suitable for ordinary engineering plastics. Has good toughness and can withstand the impact load of small and medium-sized molds.
4. Corrosion resistance
Corrosion resistance is average, and long-term contact with corrosive plastics such as PVC and flame retardant materials can cause rusting, requiring surface chrome plating or nitriding treatment.
Applicable scenarios
1. Plastic type
Suitable molds for manufacturing ordinary engineering plastic products, such as ABS, PP, PE, PS, PC, etc. Not applicable to glass fiber reinforced plastics (easily worn molds) and highly corrosive plastics (such as PVC requiring surface treatment).
2. Product type
Suitable for producing products with low requirements for mirror gloss or requiring simple textures, such as daily necessities (bottle caps, toy shells, etc.), household appliance components, automotive interior parts, etc.
3. Product output
The lifespan of injection molds made of P20 steel is around 100000 to 300000 molds. Within this range, the output is determined by the number of mold cavities, usage, and maintenance.
precautions
1. Avoid using plastics containing corrosive substances such as chlorine and fluorine unless surface treatment is carried out.
2. When stored for a long time, anti rust oil should be applied to prevent rusting caused by humid environment.
3. Complex molds can be partially embedded (such as using P20 for the cavity and higher hardness steel for the core).
     2、 718H steel
718H steel corresponds to an improved and upgraded version of P20 steel, with a domestic grade of 3Cr2NiMo. It belongs to pre hardened mold steel and is optimized for purity, uniformity, and comprehensive performance by adding nickel (Ni) elements. It is suitable for manufacturing high-precision and long-life medium and large injection molds.
core features
1. Pre hardened state
The factory hardness is 35-40 HRC, with a more uniform hardness distribution and stronger resistance to deformation. It can be directly processed to avoid dimensional fluctuations caused by heat treatment.
2. Processing performance
Excellent machinability, suitable for CNC machining and electrical discharge machining (EDM) of complex structures. Polishing performance is better than P20, reaching # 6000- # 8000 mesh, approaching the mirror effect of NAK80.
3. Wear resistance and toughness
Significantly improved wear resistance, suitable for engineering plastics filled with fiberglass and minerals. High toughness, good fatigue resistance, suitable for multi cavity molds or large molds.
4. Corrosion resistance
Better than P20, but weaker than stainless steel (such as S136), long-term contact with corrosive plastics still requires surface treatment (such as chrome plating).
Applicable scenarios
1. Plastic type
Suitable for high demand engineering plastic products, such as PA (nylon)+glass fiber (GF), PBT, PC/ABS, POM and other reinforced plastics. Transparent plastics such as PC, PMMA (acrylic), etc. require products with high surface smoothness.
2. Product type
Precision electronic components (such as connectors, housings), automotive functional components (lampshades, instrument panels), home appliance highlight panels, etc. Molds with complex structures or thin walls (good fatigue resistance).
3. Product output
The service life is 300000 to 500000 molds, which is about 30% longer than P20.
precautions
1. It is recommended to regularly check the wear of the mold cavity containing fiberglass plastic and promptly polish and repair it.
2. Avoid long-term exposure to humid environments and apply rust proof oil when storing.
3. For highly transparent plastics such as optical grade PC, it is recommended to combine mold temperature control (50-80 ℃) to optimize surface quality.
3、 NAK80 steel
NAK80 steel is a pre hardened mirror mold steel designed specifically for high gloss, high-precision injection molds. Its core advantage lies in achieving high hardness without heat treatment and excellent polishing performance, making it the preferred material for manufacturing transparent parts and high gloss surface products.
core features
1. Pre hardened state
The factory hardness is 40-42 HRC, which can be directly processed to avoid deformation during heat treatment. Excellent hardness uniformity, suitable for complex precision molds.
2. Mirror polishing performance
Polishing can reach # 10000- # 15000 mesh, which is the top level in the industry. The surface roughness (Ra) is ≤ 0.01 μ m, suitable for optical grade transparent parts (such as lenses, light guide plates) or high gloss appearance parts (such as chrome plated automotive trim).
3. Wear resistance and corrosion resistance
The wear resistance is better than P20 and 718H, but weaker than S136 stainless steel. Moderate corrosion resistance, long-term contact with corrosive plastics requires surface treatment (such as nickel plating).
4. Processing performance
Good cutting performance, but high hardness, requiring the use of hard alloy cutting tools. After electrical discharge machining (EDM), a hardened layer is easily formed on the surface and requires fine polishing.
Applicable scenarios
1. Plastic type
Suitable for high transparency/high gloss plastic products such as PC, PMMA (acrylic) COP、 Transparent ABS, etc. Not applicable to plastics containing corrosive components (such as PVC, flame retardants).
2. Product type
Optical components (camera lens, light guide plate), cosmetic packaging (bottle caps, powder boxes), automotive high gloss grilles/interior parts. Molds with complex surface textures (bite patterns, imitation leather patterns) are required.
3. Product output
The service life of the mold is around 500000 to 1 million molds, suitable for mass production of products.
precautions
1. Avoid using release agents containing sulfur and chlorine to prevent corrosion of the mold surface.
2. When stored for a long time, rust proof oil should be applied, especially in high humidity environments.
3. When injecting transparent plastic, it is recommended to control the mold temperature at 80-120 ℃ to reduce weld lines and improve glossiness.
4、 H13 steel
H13 steel is a type of hot work die steel, with a domestic grade of 4Cr5MoSiV1, designed specifically for high-temperature working environments. Its core advantage lies in excellent heat resistance and thermal fatigue resistance, making it suitable for molds that can withstand high-temperature cyclic stress for a long time.
core features
1. Hardness and toughness
After heat treatment, the hardness can reach 48-52 HRC (quenching+tempering). High toughness, better impact resistance than ordinary tool steel, suitable for high stress mold structures.
2. High temperature resistance performance
Good heat fatigue resistance, can work at 500-600 ℃ for a long time, can withstand up to 650 ℃ in the short term, is not easy to crack under alternating cold and hot working conditions, suitable for rapid cycle production, such as hot runner molds.
3. Wear resistance and corrosion resistance
Moderate wear resistance, which can be improved through surface treatment such as nitriding. Corrosion resistance is average, and long-term contact with corrosive media requires chrome plating.
4. Processing performance
The hardness in annealed state is about 180-220 HB, which is easy to cut. When precision machining is required after quenching, it is recommended to use electrical discharge machining (EDM) or grinding technology.
Applicable scenarios
1. Plastic type
Suitable for high-temperature engineering plastic products such as PEEK, PEI, LCP (liquid crystal polymer), PPS, as well as glass fiber reinforced plastic products such as PA+GF, PBT+GF (requiring high wear resistance cavities).
2. Product type
Products produced with thick walls or rapid cycles, such as car engine hoods, battery casings, and home appliance casings (such as microwave oven frames), require quick demolding. Engineering components that require high dimensional accuracy, such as electronic connectors, 5G antenna covers (LCP material), medical devices (such as surgical tool handles, PEEK material).
3. Production scale
Suitable for long life requirements of over one million cycles, especially under high temperature and high pressure conditions.
5、 S136 steel
S136 steel is a high chromium stainless steel mold steel, with a domestic grade of 4Cr13, known for its excellent corrosion resistance and polishing performance. It is specifically designed for injection molds of high cleanliness, high glossiness, and corrosive plastics, especially suitable for harsh scenarios such as medical and food packaging.
core features
1. Hardness and Wear Resistance
After heat treatment, the hardness can reach 48-52 HRC (quenching+tempering). Moderate wear resistance, can be improved by nitriding or PVD coating (such as contact with fiberglass reinforced plastic).
2. Corrosion resistance
The high chromium content (13.6%) endows it with extremely strong corrosion resistance and can be exposed to corrosive media such as PVC, flame retardants, and acidic plastics for a long time. The rust resistance ability far exceeds that of ordinary mold steel (such as P20, 718H), and no additional coating is required in humid environments.
3. Polishing property
Polishing can reach # 8000- # 12000 mesh, with a surface roughness (Ra) of ≤ 0.015 μ m, approaching the mirror effect of NAK80. Suitable for transparent plastics (such as PC, PMMA) and medical grade high cleanliness products.
4. Processing performance
The hardness of the annealed state is about 215-235 HB, and the cutting performance is good, but it is necessary to avoid sticking the tool. After electrical discharge machining (EDM), fine polishing is required to remove the white layer.
Applicable scenarios
1. Plastic type
Corrosive plastic products, such as PVC, halogen containing flame retardant materials (such as V0 grade ABS), and biodegradable plastics (containing acidic components). High transparency/medical grade plastic products, such as PC, PMMA, medical grade PP, PE (such as syringes, medication bottles).
2. Product type
Medical equipment (surgical instruments, dialysis components), food containers (bottle caps, freshness boxes), optical lenses, mobile phone lenses, cosmetic packaging (requiring mirror polishing).
3. Product output
The lifespan of the mold is over 500000 to 1 million mold cycles, especially in corrosive environments where the lifespan far exceeds that of ordinary steel.
precautions
1. Medical mold specialized machine processing to prevent oil stains or iron filings from remaining and avoid cross contamination.
2. Long term storage still requires the application of rust proof oil, especially in coastal or high humidity environments.
6、 2344 steel
2344 steel is a chromium molybdenum vanadium alloy hot work die steel with similar characteristics to H13 steel. It is designed specifically for high temperature and high pressure working conditions and has excellent heat fatigue resistance, making it suitable for harsh production environments with frequent cold and hot cycles.
core features
1. Hardness and toughness
After heat treatment, the hardness is 48-52 HRC (quenching+tempering), which balances high hardness and impact toughness. It is suitable for complex mold structures (such as thin-walled deep cavities) and reduces the risk of stress cracking.
2. High temperature performance
Can work for a long time at 500-600 ℃ and withstand 650 ℃ in the short term. Excellent thermal fatigue resistance, outstanding anti cracking ability under alternating cold and hot working conditions (such as die-casting molds), and significantly extended service life.
3. Wear resistance and corrosion resistance
Moderate wear resistance, can be improved by nitriding or coating (such as PVD). Corrosion resistance is average, and contact with corrosive plastics requires surface chrome plating.
4. Processing performance
The annealed state has a hardness of 180-220 HB, making it easy to cut, mill, and perform electrical discharge machining (EDM). When precision machining is required after quenching, it is recommended to use grinding or wire cutting processes.
Applicable scenarios
1. Plastic type
High temperature engineering plastics, such as PEEK, PEI, LCP, PPS (processing temperature>300 ℃). Containing glass fiber reinforced plastics such as PA66+GF, PBT+GF (requiring high wear resistant cavities).
2. Product type
Automotive components (such as dashboard, door panels, center console, car bumper, rearview mirror housings), electronic product housings (such as phone housings, computer housings), daily necessities (such as disposable lunch boxes, storage boxes), etc
3. Product output
Suitable for long lifespan requirements of over 1 million cycles.
precautions
Inspect the surface of the mold cavity every 50000 to 100000 mold cycles and promptly repair any microcracks or wear.
The above types of mold steel can basically meet the mold making needs of most plastic products.
